Felci FY71

Specifications

CONSTRUCTION

RCD Status:

• RCD Status: The yacht conforms with the essential safety requirements of Directive 94/25EC as (Recreational Craft Directive) and is categorised A – “Ocean”

Hull Construction:

• Composite construction using glass/Kevlar and epoxy resins with core-cell sandwich to avoid noise
• Carbon fibre bulkheads
• White painted topsides
• The deck is a composite construction made of carbon fibre to enable the lighter construction
• Topsides sprayed in white paint
• Side decks and cockpit laid in teak.
• Carbon fibre bulkheads

Deck & Superstructure Construction:

• Superstructure sprayed in white paint
• Composite construction using carbon/Kevlar and epoxy resins with core-cell sandwich
• Side decks and cockpit laid in teak.

Keel & Rudder:

• Stainless steel fin keel with lead torpedo bulb
• Glass kevlar balanced rudder with foam core and tubular stainless steel stock
• The rudder is supported by two self-aligning bearings

MACHINERY

Engine & gearbox:

• Cummins 315hp 6-cylinder turbo-charged and intercooled diesel engine.
• ZF gearbox with Aquadrive and PSS shaft seal
• Fresh water engine cooling via raw water intake and heat exchanger
• Rubber vibration damped engine space
• Twin racor fuel/water separators plus Racor filter between main and day fuel tanks

Service & Maintenance:

• Engine hours – approx. 2,000hrs as of summer 2023
• Engine serviced annually
• Complete engine overhaul at 1,600hrs
• Cruising speed – approx. 9.5-10 knots
• Maximum speed – approx. 12.5 knots
• Range at cruising speed – approx. 1,000Nm

Propulsion & Steering:

• Shaft drive with stainless steel shaft
• Bruntons Varifold 4-bladed folding propeller
• Max-Power 300 hydraulic retractable 25kw bowthruster
• Twin helm pedestals with custom laminated wood rimmed carbon fibre helm wheels

Primary Hydraulics:

• Hydraulics for inboom furling mainsail, genoa furler, bowthruster and aft tender garage with 3x hydraulic pumps
• Hydraulic PTO from generator

ELECTRICAL SYSTEMS

Voltage systems:

• 24vDC primary domestic system with 24vDC starting circuit and 220vAC via shorepower, generator or inverter.

Battery Banks:

• 32x 6vDC service batteries joined in parallel and series to supply 1,600Ah @ 24vDC – 2020
• 4x 24vDC engine and generator start batteries
• 12vDC battery bank for emergency powering of VHF and SSB (located above bilge level)

Charging / Inverter:

• 3x Mastervolt 24/100 100Amp automatic battery chargers for primary services
• Mastervolt 24/100 50Amp automatic battery charger
• Mastervolt 30Amp automatic battery charger
• Mastervolt MASS 5,000 5kw inverter

Generator:

• Onan Marine QD 17.5Kw diesel generator
• Hydraulic PTO
• Generator hours – approx. 2,000 as of summer 2023
• Generator serviced annually and completely overhauled at 1,600hrs.

Alternators:

• 24vDC 130Amp high-output engine mounted alternator for services
• Secondary engine mounted alternator

Shore Power:

• 110vAC and 220vAC shorepower systems
• 50Hz/60Hz power stabilisation transformer

PLUMBING & GAS SYSTEMS

Fresh Water:

• 24vDC pressurised fresh water system with 2x Gianneschi fresh working in parallel
• Hot water supplied by engine-driven calorifier and 220vAC 2,000w immersion heater element in well-insulated 80 litre hot water tank.
• Direct shore connection for fresh water with pressure reducer

Salt Water:

• 2x Gianneschi 24vDC salt water pressure pumps

Watermaker:

• HP450 220vAC reverse-osmosis watermaking producing approx. 450 litres per hour - 2021
• Schenker 24vDC reverse osmosis watermaker producing approx. 150 litres per hour – 2019

Bilge Pumps:

• 2x automatic bilge pumps in the sail locker
• 2x automatic bilge pumps central main bilge
• 2x automatic bilge pumps in engine room
• 2x automatic bilge pumps in aft technical compartment
• 2x automatic bilge pumps in aft lazaret
• 1x manual bilge pump
• Safety emergency engine driven high volume bilge pump

TANKAGE

Fuel:

• Approx 1,950 litres of total fuel capacity

Fresh Water:

• Approx 1,000 litres fresh water total capacity

Holding Tanks:

• Approx 200 litres black water tank capacity
• Approx 170 litres grey water tank capacity

NAVIGATION & COMMUNICATION EQUIPMENT

In Cockpit:

• B&G Hercules Race system with 8x 20/20 displays (4x at mast and 4x in cockpit)
• 2x B&G Hercules multi-function displays in cockpit
• B&G manual wind displays in aft helm cockpit
• B&G autopilot with gyrocompass with remote control
• Raymarine autopilot with gyrocompass with remote control
• Marsili hydraulic autopilot ram with electric release
• 2x Raymarine Axiom 12’’ plotters at aft helm cockpit – 2019
• 2x Raymarine Axiom 7’ chart plotters in the central cockpit – 2019
• Raymarine closed array radar scanner on transom antenna pole

Below the deck:

• 5x B&G Hercules multifunction displays (at chart table, in saloon and in accommodation cabins)
• 1 Raymarine Axiom 12” plotter – 2019
• 3x Raymarine Axiom 7’’- 2019
• Computer with 18" screen and printer
• Furuno ICS6 Navtex display with independent antenna and integration to computer system
• AIS

Communications Equipment:

• Sailor Iridium satellite phone system
• Sailor Fleet33 satellite broadband communications system
• Simrad VHF with DSC and 3x handsets
• Sailor VHF with DSC and 100w signal amplifier with external handset
• 2x independent VHF antennas
• Sailor 250w SSB transceiver
• GSM mobile phone antenna with amplifier at masthead
• WiFi access point

DOMESTIC EQUIPMENT

Galley:

• Miele 220vAC ceramic hob with Miele extractor fan above
• Miele 220vAC oven
• Miele 220vAC microwave oven
• Alpes Innox 4-burner gas stove with oven – hidden in closed compartment when not in use.
• Miele 220vAC 24-setting dishwasher
• 4x Frigomar fridges with 220vAC/24vDC dual voltage compressors
• Frigomar 233 litre freezer
• Twin inset sinks with fresh and salt water supplies

Heads:

• Tecma 24vDC electric fresh water heads
• Hot & cold pressurised fresh water showers

Laundry:

• Miele 220vAC washer dryer

Heating & Ventilation:

• Condaria 220vAC reverse cycle air conditioning system with 72,000 BTU output and 8x fancoil units. Digital thermostat controls and outlets in all cabins digit thermos in every cabins

Entertainment:

• LG LCD TV 45’’ with retractable stand
• 3x LG LCD TV 32’’ including one for use in cockpit
• HiFi system with speakers
• Seatel satellite TV receiver with decoders in each area
• Sky decoders
• FM/TV aerial

ACCOMMODATION

Summary of Accommodation:

• Up to 7 guest berths in 3-double cabins plus 3-heads with crew accommodation complete with ensuite forward

Accommodation Finish:

• Teak interior joinery throughout
• Teak soleboards with contrasting holly inlay
• White leather upholstery
• Corian counters at galley and heads
• White padded deckhead with wooden strips

Accommodation layout from Forward:

Crew Cabin

• Separated from master cabin heads via watertight door and accessible from deck.
• Single berth with ensuite heads and shower

VIP Cabin Ensuite Heads:

• Forward of VIP cabin with heads and shower.

VIP Cabin:

• Full beam guest cabin with offset double berth to starboard.
• Settee seating to port can be converted to a bed
• Hanging lockers to port and starboard.

Saloon:

• Large u-shaped settee seating to starboard with seating/dining for up to 10.
• Desk area/workstation opposite to port with retractable TV

Galley:

• Aft of saloon area to port.
• U-shaped galley configuration with electric appliances plus further gas stove with oven

Master Cabin:

• Accessed aft of saloon on starboard side.
• Full beam cabin with centreline double berth.
• Ensuite heads with separate shower cubicle.
• Hanging lockers and second navigation station to starboard
• Access through to aft navigation station and accommodation areas

Port Aft Guest Cabin:

• Accessible from aft cockpit or through to main accommodation via master cabin.
• Twin berths
• Ensuite shower with heads.

Navigation Station:

• Opposite port aft guest cabin to starboard.
• Accessible from helm cockpit via companionway
• Accessible to main accommodation via door to master cabin.

Machinery Space:

• Full sound-proofed machinery space access from navigation area aft to starboard.

DECK EQUIPMENT

Rig:

• Hall Spars carbon fibre mast – white painted
• Keel-stepped fractional rig with 3-sets of swept back spreaders
• Marten carbon fibre boom with hydraulic inboom furling system – white painted
• Carbon fibre spinnaker pole 9m – presently in Italy
• Navtec stainless steel rod standing rigging
• Split backstay with PBO terminals
• Hydraulic genoa furler
• Manual staysail furler on removable stay with hydraulic tensioner
• Manual furler for drifter on removable stay set to bow anchor fitting
• Retractable carbon fibre bowsprit for use with gennaker
• All mast control line and halyards led aft to cockpit
• Checkstays
• Removable inner forestay for storm jib
• Harken deck gear
• Navtec 5-way hydraulic control panel connected to Cariboni hydraulic backstay, genoa halyard, genoa forestay tensioner, staysail stay tensioner and vang. Electronic and manual controls for all cylinders with push-buttons at port and starboard helms
• Control system allowing angle of vang to be automatically set prior to furling of mainsail
• Spinnaker pole

Winches:

• 6x Harken carbon-top self-tailing electric winches positioned around aft helm cockpit

Sails:

• Millenium Sails carbon/Kevlar monolithic fully-battened 148sqm mainsail
• Spare main sail
• 2x Millenium Sails carbon/Kevlar monolithic furling 109sqm genoas (summer and winter sails)
• Millenium Sails carbon/Kevlar monolithic furling staysail
• Millenium Sails carbon/Kevlar monolithic furling 160% drifter
• Gennaker
• Storm sails

General:

• Central guest cockpit with large U-shaped bench for 10 people.
• Cockpit table with folding leaves, height adjustable on electric pistons, to create large sunpad area.
• Cockpit fridge
• Transom antenna poles for radar, satellite phone antenna and satellite TV antenna
• Solimar flush deckhead hatches
• Retractable hydraulic passarelle with garage access crane functionality.
• Aft tender garage with large aft hydraulically door. For storage of outboards and water toys.
• Aft sunbathing area with built-in teak platform.
• Removable carbon swim ladder.
• Salt-water shower on swim platform.
• Tender chocks on foredeck for RIB tender stowage using halyards for launching/recovery

Exterior Lighting:

• Fibreoptic lighting for cockpit and bulwarks
• Spreader up and down lighting

Anchoring & Mooring:

• Lofrans 2,500w 24vDC electric reversing anchor windlass with remote control
• 80kgs CQR anchor with 160m of chain
• Sanguinetti 2,000w retractable mooring windlass
• Warps and fenders

Covers, Cushions & Canvas:

• Sprayhood with stainless steel frame with cockpit enclosure
• Bimini with stainless steel frame
• Sunbathing cushions

Tender & Outboard:

• AB380 3.80m aluminium bottomed inflatable RIB tender
• 2x 25hp 2-stroke outboard engines

Diving Equipment:

• 50 litre dive compressor system with charging for up to 6 dive bottles

Spares:

• The boat is equipped with a 40’ container with spare parts and sails

SAFETY EQUIPMENT:

General note on safety equipment: Any safety equipment such as liferafts, Epirbs, fire extinguishers and flares etc. are usually personal to the current owner(s) and if being left on-board as part of the sale of a used vessel may require routine servicing, replacement, or changing to meet a new owners specific needs.

Life saving:

• 406Mhz EPRIB
