Tracker Pro Guide V-175 Combo

Additional Specs

• Length:17' 7"

• Length w/Swim Platform: 18' 5"

• Beam: 8' 1"

• Bottom Width: 6' 10"

• Max. Recommended HP: 150 HP

• Fuel Capacity: 25.5 gal.

• Max. Person Capacity: 6 persons

• Max. Person Weight: 835 lbs.

• Max. Person, Motor & Gear Weight: 1600 lbs.

• Interior Depth: 26.75"

• Transom Height: 25.5"

• Deadrise At Bow: 35 degrees

• Deadrise At Transom: 20 degrees

• Draft: 14"

• Hull Material: 0.1 5052 marine alloy

• Average Dry Weight: 1525 lbs.

• Average Package Weight: 2985 lbs.

• Package Height: 7' 3"

• Package Width: 8' 6"

• Towing Length: 24' 8"

• Storage Length (w/Outboard Trimmed Down): 22' 0"

Standard Features

Comfort, Convenience & Peace of Mind

• Backed by the TRACKER® PROMISE—the best factory warranty in aluminum boats

• Limited lifetime hull warranty

• NMMA® certified

• Flotation meets or exceeds NMMA® & U.S. Coast Guard requirements

• Easy-fill EPA-compliant fuel tank

• Bow & stern eyes

• 6 flip-up cleats including 2 midship cleats

• Aft swim platform w/boarding ladder

• Removable ski tow pylon

• Motor-stop safety lanyard

• Fire extinguisher

• Horn

• Paddle

Livewell System

• Bow 19-gal. (71.92 L) aerated livewell w/timer, recirculator & pump-out system

• Aft 29-gal. (109.78 L), 50" (1.27 m) aerated livewell w/removable bait bucket, timer, recirculator & pump-out system

• Dual 500 GPH (1,892.71 LPH) aerator/fill pumps

• Dual 500 GPH (1,892.71 LPH) recirculating/pump-out pumps

• Molded 1-piece construction w/rounded corners for easy cleanup & to protect your catch

• Adjustable aerator heads for maximum water control

Trolling Motor

• Minn Kota® PowerDrive™ 12V, 55-lb. (24.95 kg) thrust, 54" (1.37 m) shaft, foot-control trolling motor

• Thru-bolted trolling motor mount for extra strength

Console

• NEW port & starboard rotomolded consoles w/tempered safety-glass walk-thru windshields & hatch

• Passenger console w/storage compartment, drink holder & small items tray

• Enclosed console bottom(s) w/removable panel

• Lowrance® HOOK Reveal 5 swivel color fishfinder + GPS w/CHIRP & SplitShot™ transducer

• Soft touch sport steering wheel

• BayStar® tilt hydraulic steering

• Starboard weather-protected AM/FM Bluetooth®-capable stereo

• Strategically placed instruments w/recessed gauges for easy visibility & reduced glare

• Illuminated speedometer, tachometer, voltmeter, fuel gauge, water pressure gauge & trim gauge

• Toggle switches

• Black Metallic instrument & switch panel

• Mercury® throttle control mount

• Charcoal console color

Interior

• 7 pedestal seat base locations

• 2 movable & folding fishing seats w/360°-swivel & lock, & sturdy 2-3/8" (6.03 cm) seat pedestals

• Carpeted trolling motor deck w/drink holder

• Elevated bow & aft fishing decks w/large bow storage lids for easier access

• Large bow storage area w/lids & cable door restraints

• Bow starboard compartment box w/large, carpeted storage

• Bow center lockable rod box w/organizer for spinning & baitcast rods to 7' 6" (2.29 m)

• Port & starboard below-console storage w/lockable angled footrests

• 1 movable & folding driver/fishing seat w/sliding base adjustment, 360°-swivel & lock, & sturdy 2-3/8" (6.03 cm) seat pedestal

• Top-loading port side lockable rod box for rods to 7' 6" (2.29 m)

• Port deck rod hold-down straps

• Top-loading starboard side lockable rod box for rods to 8' (2.44 m)

• In-floor center gear storage compartment

• Aft center deck step w/lockable storage & 2 drink holders

• Aft deck w/split flip sections & 18"-wide (45.72 cm) jump seats

• Exclusive VERSATRACK® accessory-mounting channel in gunnels

• 16-oz. (.45 kg) marine-grade, fishing-friendly carpet on decks & trim

• Low-maintenance commercial-grade, chemical-resistant vinyl cockpit floor

Performance

• Deep deadrise & reversed chines for a smoother, drier ride & better overall performance

• Pressed-in strakes for optimal performance

• Factory-matched, performance-tested propeller

Construction & Exterior

• NEW TRACKER® hullside graphics

• Color: DIAMOND COAT™ Starlite Black, Starlite Blue or Starlite Red gunnels & hull sides w/Starlite Gray bottom

• DIAMOND COAT™ 3.0 finish — an industry-exclusive powdercoat for brilliant durability

• All-welded, 2-piece .100 aluminum Deep V hull w/wide beam & stable bottom for a smoother, drier ride in rough waters

• Expanding foam injected into hull cavities for added hull stiffening, flotation & a quieter ride

• Pressed-in hull strakes for enhanced performance

• Reverse chine hull design for drier ride & better handling

• Transom motor-mounting plate for increased strength & durability

• Welded-in longitudinal stringer system for full-length support along the running surface

• Pressure-treated floor & deck(s) w/limited lifetime warranty

• Molded bow storage box/cooler w/raised lip for drier storage

Electrical

• 800 GPH (3,028.33 LPH) bilge pump

• Stowable navigation lights w/LED courtesy light at bow

• Bow & console courtesy lights

• Battery charger

• 2 battery trays

• Interstate® batteries: 1 cranking & 1 trolling

• Bow panel w/trolling motor receptacle, 12V outlet & motor tilt switch

• Passenger console-mounted 12V outlet

• Wiring system wrapped in abrasion-resistant protective conduit

Trailer

• Custom-fit, single-axle trailer powdercoated w/GALVASHIELD® Impact corrosion & chip protection for improved durability

• Chrome wheels & matching hub covers w/14" (35.56 cm) radial tires

• Hubs designed for quick & easy hub lubrication

• NEW spare tire carrier w/matching spare tire

• Space-saving swing-away tongue to reduce storage length

• Pivot-up locking jack w/swivel wheel

• Heavy-duty winch w/nylon strap & bow safety strap

• Outboard motor support to reduce hull & transom stress while towing

• Heavy-duty upright load guides for easy, centered loading

• Carpeted bunks & fender boards to protect hull

• Submersible LED lighting

• Nylon tie-down straps (supplied w/boat package)

• Safety cables
