Ranger Z518 Cup-Equipped

Additional Details

Additional Specs

• Length:18' 10"

• Beam: 97"

• Max. Recommended HP: 200 HP

• Engine Shaft Length: 20"

• Inside Depth: 21"

• Fuel Capacity: 39 gal.

• Livewell Capacity: 24 gal.

• Total Person, Motor, Gear: 1350 lbs.

• Approximate Boat Weight: 1650 lbs.

• Rod Box Length - Port: 8' 0"

• Rod Box Length - Center: 8' 0"

• Max. Person Capacity: 4 persons

• Trailer GVWR: 3725 lbs.

• Approximate Length On Trailer w/ Motor Down (May vary with engine model and set-back plate): 23' 7"

• Approx Length On Trailer w/Motor Down/Swing Tongue Open (May vary with engine model/set-back plate): 21' 7"

• Width On Trailer: 102"

Standard Features

Custom Details

• Power Ventilation Rod Storage™

• Integrated center-storage rod & tackle management system

• Stainless steel push-to-close locking latches

• Carpeted rod storage w/ organizers

• Ranger® tournament measuring board integrated at front deck step

• Runnin' rod rack w/ retractable strap

• Remote drain plug

• Tool holders at bow and front deck step

• Molded-in driver / passenger footrests

• Integrated stainless steel cup holders

Ranger Cup Equipped - GARMIN® Package

• GARMIN® Live Scope™ Plus LVS34 Live Sonar

• GARMIN® Force 45" 24V Trolling Motor

• Dual Pro™ on-board charger, 15A x 3 bank w/ auto-detect technology & remote charging port

• Foot Throttle w/ Slide

Ranger Cup Equipped - LOWRANCE® Package

• Lowrance® HDS® 9 PRO at bow

• Lowrance® Active Target™ 2 Live Sonar

• Lowrance® Ghost 45" 24V Trolling Motor

• Dual Pro™ on-board charger, 15A x 3 bank w/ auto-detect technology & remote charging port

• Foot Throttle w/ Slide

Electronics

• Multi-function custom gauge package: speedometer, tachometer, fuel, trim, water pressure, temp & volt

• Easy-touch analog switching

• Keyed ignition

• Ranger® Umbilical™ dedicated bow-to-stern 6-gauge electronics wiring harness w/ 30A breaker

• Heavy Duty 6-gauge trolling motor wiring harness w/ 60A breaker

• Master Power on/off battery disconnect switch

• NOCO™ GB40 jump starter w/ on-board USB charging

• LED storage compartment lighting & LED courtesy & livewell lighting

• Integrated LED bow navigation lights & removable LED anchor light

Power/Performance

• Ranger Cup Equipped Trolling Motor (see RCE Package)

• AGM Starting battery w/ tray

• (2) Trolling Battery trays (tray only)

• One-Piece-Feel Interloc Construction

• Pultruded Fiberglass Transom

• Integrated engine setback

• Hydraulic steering

• Recirculating aerated livewell w/ removable divider

• Venturi aeration system

• Recessed trolling motor foot pedal

• High performance stainless steel prop

• Foam-filled fiberglass stringer system

Safety/Comfort

• Upright Level Flotation exceeding all USCG & NMMA standards

• Fire extinguisher & horn

• Stainless steel seat bases

• Pop-up tie cleats

• Integrated grab handles

• Rite Track Keel®

• Automatic & manual bilge pumps

• Boarding ladder

Trailer Features

• Ranger® Boats Road Armor Equipped® trailer protectant coating

• 15" Machined/painted Raptor wheels w/ matching spare

• Ranger Trail® Vault® Hub lubrication system

• Fiberglass fenders w/ step pads

• Hydraulic surge disc brakes

• Swing-away tongue

• Integrated center-swing jack finished in black powdercoat

• Stainless steel ratcheting tie-downs

• LED lighting

• LED back-up lights

• NMMA®/NATM certified
