Perini Navi 40M Sloop

Full Specs

MAIN CHARACTERISTICS

Builder: Perini Navi S.p.A. (Italy)

Model: Perini Navi 40M Sloop S/Y

Hull No: C.2180

Naval Architecture: Ron Holland Design / Perini Navi

Exterior Design: Perini Navi

Interior Design: Perini Navi

Type: Sailing Yacht / Sloop / Superyacht

Hull Material: Aluminium

Superstructure Material: Aluminium

Decks: Teak

Keel: Centreboard with fixed ballast of 17 Tons

Year Built: 2013

Refit: 2020

LOA: 39.40 m (129’ 3”)

LWL: 34.10 m (111’)

Beam: 9.13 m (31’)

Maximum Draft: 9.10 m (29’ 10”)

Minimum Draft: 3.50 m (11’ 6’’)

Gross Tonnage: 254 GT

Displacement: 220,000 kg (485,017 lb)

Classification: ABS, MCA + A1, Commercial Yachting Service, ✠ AMS, MCA LY2 Short Range

Flag of Registry: Malta

Location: South of France



PROPULSION

Type / Fuel: Single Diesel

Main Engine: 1 x 670 Hp (500 kW) CATERPILLAR C18 @ 2100 RPM

Engine Hours: TBD h (Dec. 2022)

Maximum Speed: 14 knots

Cruise Speed: 10.5 knots

Economical Speed: 7 knots

Range: 3000 NM @ 7 knots

Drive: Straight NI-AOL Bronze S/S shaft, brake on water lubricated bushing

Gearbox: HUNDESTED CPG- 32

Elastic Coupling: VULKAN

Steering System: MARSILI Electro-hydraulic

Propeller: HUNDESTED 4-blade CP



TANKAGE

Fuel Capacity: 14,400 l (3,800 US Gallons)

Fresh Water Capacity: 5,000 l (1,100 US Gallons)

Lube Oil: 486 l (128 US Gallons)

Dirty Oil Tank: 430 l (113 US Gallons)

Grey / Black Water: 1,324 l (350 US Gallons)

Bilge Water: 916 l (242 US Gallons)



SAILS & RIGGING

Sailing system designed & built by Perini Navi, handled semi-automatically

Operation via 1 console or a joystick

Monitoring system allows continuing verification of sailing systems status

Total Sail Area Upwind: 893 m2 (9,612 ft2)

Main Sail: 378 m2 (4,069 ft2)

Reacher: 515 m2 (5,543 ft2)

Jib: 301 m2 (3,240 ft2)

MPS: 900 m2 (9,688 ft2)



SET OF SAILS

DOYLE full batten main with 2 reefs: 370 m2 (2016)

DOYLE tri-radial blade with 2 reefs: 300 m2 (2020)

DOYLE tri radial carbon spectra reacher: 510 m2 (2016)

DOYLE asymmetric (A2) with sock & bucket: 900 m2

NORTH SAILS small delivery Mainsail (2020)



MAST & RIGGING

SOUTHERN SPARS High Modulus carbon mast & boom

Height Above DWL: 51 m (170’)

Rigging (Standing): EC6 carbon fibre

Carbon fibre mainsail furling boom

BAMAR furlers for jibs and reacher

New generation Perini Navi captive reel winches

RONDAL carbon hatches

Carbon fibre tender lifting pole with captive winch

NAVTEC double acting hydraulic vang

NAVTEC hydraulic backstay



ACCOMMODATION

9 Guests in 4 en-suite Staterooms

Guest Cabin Configuration:

• 1 x Master
• 2 x Doubles
• 1 x Twin (convertible to double) with additional Pullman bed

This sailing yacht features a split-level saloon area which offers increased headroom and creates two social areas on the main and lower decks. Her full-beam Master Suite offers a large Turkish Hammam steam shower, "Therasage" massage & shiatsu machine and fully equipped gym area with Technogym cross trainer, rowing machine, free weights and exercise bars. Two Queen-size double cabins and a further convertible twin cabin with Pullman create accommodation for up to 9 guests in total

Crew Accommodation:

• 6 x Crew in 3 cabins
• Captain’s double cabin with en-suite facilities
• 2 x Bunk-bedded cabins with en-suite facilities

Crew mess

Fully equipped galley and laundry on forward lower deck



SURFACE DIMENSIONS

Total Deck Area: 258 m2 (2,777 ft2)

Cockpit Area: 32 m2 (344 ft2)

Saloon & Wheelhouse Area: 73 m2 (786 ft2)

Total Owner & Guest Cabin Area: 83 m2 (893 ft2)

Total Crew Area: 54 m2 (581 ft2)

Headroom: 2.05 m (6’ 9”) in all guest areas



LAYOUT

Dining Room:

• Dining table for 8 guests
• 8 x Dining chairs
• 2 x Double couches
• 2 x Armchairs
• Bench for 4 guests
• 3 x Coffee tables
• 2 x Sub-zero wine cellars, total 40 bottles
• Concealed TV

Upper Saloon:

• 6-Seater sofa
• Carbon designer chair
• 2 x Chairs
• Coffee table
• Concealed TV
• Day head portside forward

Master Suite:

• King-size bed
• En-suite bathroom with shower
• Sanitary
• 2 x Night tables with drawers
• TV flat screen
• Large bulkhead wardrobe with hanging lockers and drawers
• Office desk with one chair
• Pull-out massage bed
• Digital safe

Owner’s Gym:

• Rowing machine - CONCEPT 2 Model E
• Cross trainer - Synchro TECHNOGYM 700iE

Aft Starboard Cabin:

• Twin beds (convertible to double)
• En-suite bathroom
• Additional Pullman bed
• Under the bed storage
• Night table with drawer
• Wardrobe, drawers, shelves and mirror
• TV LCD

Forward Starboard Cabin:

• Queen-size bed
• En-suite bathroom
• Under the bed storage
• Night table with drawer
• Wardrobe, drawers, shelves and mirror
• TV LCD

Forward Portside Cabin:

• Queen-size bed
• En-suite bathroom
• Under the bed storage
• 2 x Night tables with drawers
• Wardrobe, drawers, shelves and mirror
• TV LCD

Crew Mess:

• U-shaped dining table and seating
• Dishwasher
• Small fridge

Captain’s Cabin:

• Double bed
• En-suite bathroom
• Drawers under the bed
• Wardrobe, drawers, shelves and mirror
• TV LCD
• Digital safe

Crew Cabins:

• 2 x Bunk bedded cabins
• Each with shower and toilet
• Each with Stereo and DVD players
• Each with clothes hanging wardrobe



OTHER MACHINERY

Thrusters: 2 x 75 Hp retractable HUNDESTED (hydraulics powered via PTO on gearbox)

Fire & Emergency Pumps: 2 x 380 CV GIANNESCHI 470 l/m bilge & fire pumps, 1 x Diesel bilge & fire pump

Bilge Pumps: 8 x 24V Automatic

Air Conditioning: CONDARIA, throughout the sailing yacht

Boilers: 2 x 100 l with 2 x heating 2.5kW each

Watermakers: 2 x IDROMAR 125 l/h

Sewage System: SELMAR (17-pax rated)

Oily Water Separator: Filtering system



ELECTRICAL EQUIPMENT

Electrical Circuits:

• 380V / 50Hz 3-phase
• 220V / 50Hz single phase - lighting & low power machinery
• 24V DC - emergency lighting, electronics instruments & alarms

Shore Power: ASEA 63kVA frequency converter, seamless transfer capability

Generators: 2 x 68 kW CATERPILLAR C4.4 380V - 50Hz @ 1500 RPM

Generator Hours: TBD h (Dec. 2022)

Emergency Generator: 4 kW 380V - 50Hz @ 3000 RPM

Batteries:

• Bank of Gel 24V 400A Services
• 1 x Gel 24V 400A Emergency lights
• 1 x Gel 24V 200A Main engine starting
• 2 x Gel 24V 150A Generator starting
• 1 x Gel 12V 100A Emergency Generator starting



NAVIGATION EQUIPMENT

Engine Gear:

• CAT electronic engine displays
• CAT electronic engine controls

Autopilot:

• A&T GPD Pilot Display (wheelhouse)
• B & G H3000 GPD Pilot Display (external)
• B & G Rudder (steering)

Radar / Chart Plotter:

• HATTELAND Mini CPU w/pa 2.4G processor with 17’ monitor (wheelhouse)
• FURUNO Blackbox Navnet 3D SXGA Chartplotter (wheelhouse)
• FURUNO Black Box Navnet 3D SXGA colour Chartplotter (external)
• 1 x 12.9” iPad Pro with Navionics back up

Horn: TYFON MKT 75 / 660

Navtex System: FURUNO LCD

AIS:

• FURUNO FA 150
• SAILOR SART 2

Fleet Broadband: VSat

EPIRB: 2 x SAILOR SGE406

Compasses:

• B&G H3000 Halcyon Gyro
• FURUNO rate compensated heading sensor
• HEIN & OETTING Venus Magnetic compass

Depth Sounder: FURUNO Network Sounder, Navnet Fishfinder

GPS: FURUNO GP150

Wind Instruments:

• B &G 3000 Hercules Pack system complete with:
• 1 x Heel, 1 x Standard 213 masthead, 1 x Depth
• 1 x Paddle wheel

Wheelhouse:

• Analogue wind direction
• Analogue wind speed indicator
• Analogue magnified instrument
• Analogue boat speed instrument
• 2 x GFDs

External:

• 4 x B&G Triton multi-displays (2020)
• 1 x B&G GFDs

Crew Area:

• 2 x JUMBO 20.20
• 1 x GFD, crew mess
• 1 x GFD in captain’s cabin



COMMUNICATION EQUIPMENT

GMDSS Radios:

• 1 x SAILOR TT 3000EB
• 2 x SAILOR SP3520 portable VHF

VHF Radio Telephones:

• 2 x SAILOR 6215 & 6222 DSC VHFs (wheelhouse)
• SAILOR C4901 Control Handset (wheelhouse)
• SAILOR C4901 Control Handset VHF A1 (external)
• SAILOR C4901 Control handset/speaker (crew mess)

Internet Connections:

• 2 x SAILOR 250 broadband
• 1 x COBHAM 800 antenna
• PEPWAVE Wi-Fi router

Telephone Exchange:

• PANASONIC KX-TDA 100
• 9 x KX-DT343 telephone units
• 8 x KX-TDA0142 4 channel DECT base stations
• 6 x KX-TCA256 DECT handsets
• Watertight stainless-steel-cased door phone for use either side at side boarding or gangway boarding

Ethernet LAN Network: DELL PE860 Power Edge server computer



ENTERTAINMENT EQUIPMENT

A/V System: Audio visual system based around Control 4 Processors & remote controls

Main Saloon:

• PANASONIC 42" Plasma display TV
• 6000 Kaleidescape system
• SAMSUNG Blue ray BP-P1500 disc player
• Airplay control with Chromecast system
• Bluetooth throughout the upper saloon

Lower Saloon:

• PANASONIC 42" Plasma display TV
• 6000 Kaleidescape system
• Airplay

Owner’s Suite:

• PANASONIC 4" Plasma TV
• 6000 Kaleidescape system
• SAMSUNG Blue ray BP-P1500 disc player
• Airplay control & Apple TV

Owner’s Study:

• Speakers & CRESTRON wall mount LCD controller

Gym:

• 15" LCD TV with speakers

Starboard Twin Cabin:

• SHARP 20" Aquos LCD TV
• 300 Kaleidescape system

Portside Forward Cabin:

• SHARP 32" Aquos LCD TV
• 300 Kaleidescape system
• Bluetooth & Airplay

Starboard Forward Cabin:

• SHARP 32" Aquos LCD TV
• 300 Kaleidescape system
• Bluetooth & Airplay

Crew Mess:

• PHILLIPS 15" LCD TV
• Kaleidescape

Captain’s Cabin:

• PHILIPPS 15" LCD TV

Crew Cabins:

• Stereo & speakers

Satellite TV:

• SEATEL Cobham VSTA (new 2016) with independent receivers for the Master cabin, upper & lower saloons

Bow Sunpad:

• Control 4 Deck tablet
• 2 x PROMAR speakers

Aft Cockpit:

• Airplay control with Chromecast system
• 2 x PROMAR speakers
• PANASONIC 40" LCD TV

Helm Pod:

• 2 x PROMAR speakers



GALLEY & LAUNDRY EQUIPMENT

Galley:

• Industrial 6-burner stove
• Range hood variable speed in stainless-steel
• MIELE oven M399B
• MIELE Jubilee SC dishwasher
• ELITECH fridge
• ISE macerator
• Expresso machine
• 2 x Microwave ovens

Refrigeration / Freezers:

• Custom in galley, 1300 l
• Deep freezer
• Custom in aft cockpit, 150 l
• Custom in bilge storage, 1000 l

Laundry:

• 2 x 6kg Professional MIELE washing machines
• 2 x 6kg Marine dryers
• World hinged iron board
• Flatwork ironer
• Laundry connected to crew mess

Crew Mess:

• Fridge
• Trash compactor
• Sink station
• Dishwasher
• Flush mounted access to under floor deep freeze

Garbage locker in forepeak



DECK EQUIPMENT

Anchor Windlasses: 2 x Hydraulic hinging anchor bowsprits NANI

Aft Mooring Winches: HARKEN 1120 3-speed

Anchors: 2 x Stainless-steel CQR 182kg with 16mm chains

Passerelle: PINCRAFT

Boarding Ladder: PINCRAFT (starboard)



SAFETY & SECURITY EQUIPMENT

Compliant with MCA rules for safety equipment

2 x Life rafts (8-people)

1 x Life raft (6-people)

Life rings

ABS and MCA approved life jackets

FM 200 firefighting plant

Fire extinguishers

Fire crew equipment

CCTV2

Speed Dome PTZ (spreaders)

Speed Dome PTZ (engine room)

(Both connected to 17" LCD in Wheelhouse & Crew Mess)



TENDERS & WATERSPORTS

PASCOE 5.50m RIB with inboard YANMAR engine 150 Hp (refitted 2020)

2 x Stand-up paddleboards

Water skis (adult & children)

Inflatable Yacht Pool

Snorkelling gear

Full deep-sea fishing equipment (fighting chair, multiple rod, reels & tackle)



REFIT SUMMARY (WINTER 2019-2020)

Main engine top end overhaul

2 x New Generators

Rig out, checked & polished

Jib / Blade sail - new July 2020

Tanks pumped out, pressure washed & cleaned - October 2020

Teak decks 90% re-caulked - July 2020

Yacht Brochure

Available on request.

Inspections

Prior appointment, please.

Berth

Berth place management possible on French or Italian Riviera as well as Spain (Mainland and Balearic Islands), Greece and Turkey.

Disclaimer

These particulars are given in good faith as supplied to us but cannot be guaranteed and cannot be used for contracts
